Mono Extrusion Coating Machine

Applications

Release Paper Coating

Release Paper Coating

Machine Features

Extruder

Extruder

  • Extruder equipped with a PID temperature controller, the setting temperature can accuracy control.
  • The extruder can work in conjunction with a changeable pressure adaptor and a screen changer to obtain convenient pressure adjustment for different resin components and let machine stable production.
  • The working width of T-die can be adjusted during machine production.
  • No need to adjust the die lip can change the coating thickness.
  • Film edges are stable flow rate and can control thickness.
Anchor coating device / Dryer

Anchor coating device / Dryer

The anchor coating device equips flat roller or mesh roller as coating cylinder and high efficient dryer can save floor space and power. Very easy for maintained.

Automatic Control System / Human Machine Interface

Machine is equipped with an automatic control system so the operator can control it easily.

The human machine interface panel displays operational status and information. Through the control panel, parameters can be easily set and saved in the memory. Such functions provide convenient operation and consistent quality.

Winder

Winder uses a turret type auto-
splicing system.

Edge trimming

Equipped with vacuum suction system for edge trimming, let operating easier.

Cooling Roller

Special design for inner channel of cooling roller ensures perfect temperature uniformity.

Unwinder

Unwinder uses a turret type auto-splicing system.
Add to
Inquiry form
Specifications
Model YSJ YSJ-D
Working Material BOPP film, CPP film, PET film, Cellophane, Aluminum foil, Paper, Non-woven fabric, PE film, Nylon film
Resin PP / LDPE / LLDPE / EVA / EAA / SURLYN
Extruder Output 75 ~ 400 KG / HR
Coating Thickness 0.01 ~ 0.03 MM
Machine Speed 160 / 250 / 300 M / MIN
Working Width 500 ~ 1600 MM
Unwinder Diameter 500 ~ 1200 MM
Rewinder Diameter 500 ~ 1200 MM
Co-extrusion feedblock 2 kind / 2 layer or 3 layer, 3 kind / 3layer
Co-extruder Multi-layer T-die 2kind / 2layer
